Benefit from our many years of experience and expertise in the field of plastic strapping. We offer you not only high-quality plastic strapping bands but also the appropriate strapping machines, each tailored to the specific requirements of your application.
In the strapping machine segment, we can generally distinguish between semi-automatic machines, where the strapping band is manually guided over the package, and automatic machines, where the band is automatically applied around the goods by a frame. Additionally, strapping machines can be differentiated by the type of packaged goods, i.e., packages or pallets. The most common machine types can be found in the following overview.
Automatic strapping machine, 850x600 mm standard arch, 15-75 kg tension force, sealing by heating element, for PP strapping with 200 mm core ID (option: 280 mm), for 9 mm strap wide, up to 30 strapping cycles per minute, working height: 800 mm, machine layout: 1,440x600x1,520 mm (LxWxH)
Automatic strapping machine, 850x600 mm standard arch, 15-70 kg tension force, sealing by heating element, for PP strapping with 200 mm core ID (option: 280 mm), for 12 mm strap width, 24 strapping cycles per minute, working height: 800 mm, automatic strap feed, electronic tension control, automatic strap ejection, machine layout: 1,440x600x1,520 mm (LxWxH)
Automatic high speed strapping machine, 650x400 mm standard arch, for PP strapping with 200 mm core ID, 5 mm strap width, appr. 50 strapping cycles per minute, electronic tension control, automatic strap feed, automatic strap ejection, with 2 foot pedals (front and rear), working height 830 - 950 mm, machine layout: 850x580x1.330 (L x B x H)
Automatic strapping machine, 850x600 mm standard arch, 15-75 kg tension force, sealing by heating element, for PP strapping with 200 mm core ID (option: 280 mm), for 12 mm strap wide, up to 30 strapping cycles per minute, working height: 800 mm, machine layout: 1,440x600x1,520 mm (LxWxH)
Semi-automatic pallet strapping machine for 15-16 mm strap width recommended tape thicknesses: PP 0,4-0,8mm I PET embossed: 0,4-0,7mm I PET smooth: 0,4-0,6mm, PalettPlus FX is the standard version for semi-automatic palett strapping. You fold down the track manually and move it below the pallet. After pulling it over the packaging good, the strap is put in the machine which subsequently pulls the strap tight, seals and cuts it.
Semi-automatic pallet strapping machine with automatically movable track, suitable for both PP and PET strapping with 12 mm strap width, recommended tape thicknesses: PP 0,4-0,8mm I PET embossed: 0,4-0,7mm I PET smooth: 0,4-0,6mm,15-100 kg tension force, 550 mm sealing height, machine layout: 1,005x765x1,120 mm (LxWxH)
Semi-automatic pallet strapping machine with automatically movable track, suitable for both PP and PET strapping with 16 mm strap width, recommended tape thicknesses: PP 0,4-0,8mm I PET embossed: 0,4-0,7mm I PET smooth: 0,4-0,6mm, 15-100 kg tension force, 550 mm sealing height, machine layout: 1,005x765x1,120 mm (LxWxH)
Semi-automatic strapping machine, for PP strapping on core ID 200 mm (option: 280 mm), for 6-16 mm strap width, appr. 25 strapping cycles per minute, 15-45 kg tension force, 780 mm working height, machine layout: 902x575x780 mm (LxWxH)
Semi-automatic strapping machine, for PP strapping on core ID 200 mm (option: 280 mm), for 5-16 mm strap width and >= 0.4 mm strap thickness, appr. 30 strapping cycles per minute, 5-45 kg tension force electronically adjustable, 750-830 mm adjustable working height, machine layout: 845x430x750 (LxWxH)
Automatic strapping machine, 850x600 mm standard arch, 15-70 kg tension force, sealing by heating element, for PP strapping in 9 mm with 200 mm core ID (option: 280 mm), 24 strapping cycles per minute, working height: 800 mm, automatic strap feed, electronic tension control, automatic strap ejection, machine layout: 1,440x600x1,520 mm (LxWxH)
